| d2 | d1 | s | a | weight kg/1000pcs | d2 | m | n | d3 | FN | Fs | g | Fsg | n abi | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| nominal size | min | max | tolerance | tolerance | tolerance(h11) | tolerance | min | max | kN | for d1 | kN | min.-1 | |||||||
| 0.8 | 1 | 1.4 | 0.2 | ±0.02 | 0.58 | ±0.04 | 0.003 | 0.8 | 0-0.04 | 0.24 | +0.040 | 0.4 | 2.25 | 0.03 | 1.2 | 0.08 | 0.3 | 0.04 | 50000 |
| 1.2 | 1.4 | 2 | 0.3 | ±0.02 | 1.01 | ±0.04 | 0.009 | 1.2 | 0-0.06 | 0.34 | +0.040 | 0.6 | 3.25 | 0.04 | 1.5 | 0.12 | 0.4 | 0.06 | 47000 |
| 1.5 | 2 | 2.5 | 0.4 | ±0.02 | 1.28 | ±0.04 | 0.021 | 1.5 | 0-0.06 | 0.44 | +0.040 | 0.8 | 4.25 | 0.07 | 2 | 0.22 | 0.6 | 0.11 | 43000 |
| 1.9 | 2.5 | 3 | 0.5 | ±0.02 | 1.61 | ±0.04 | 0.04 | 1.9 | 0-0.06 | 0.54 | +0.050 | 1 | 4.8 | 0.1 | 2.5 | 0.35 | 0.7 | 0.17 | 40000 |
| 2.3 | 3 | 4 | 0.6 | ±0.02 | 1.94 | ±0.04 | 0.069 | 2.3 | 0-0.06 | 0.64 | +0.050 | 1 | 6.3 | 0.15 | 3 | 0.5 | 0.9 | 0.24 | 38000 |
| 3.2 | 4 | 5 | 0.6 | ±0.02 | 2.7 | ±0.04 | 0.088 | 3.2 | 0-0.075 | 0.64 | +0.050 | 1 | 7.3 | 0.22 | 4 | 0.65 | 0.9 | 0.32 | 35000 |
| 4 | 5 | 7 | 0.7 | ±0.02 | 3.34 | ±0.048 | 0.158 | 4 | 0-0.075 | 0.74 | +0.050 | 1.2 | 9.3 | 0.25 | 5 | 0.95 | 1 | 0.47 | 32000 |
| 5 | 6 | 8 | 0.7 | ±0.02 | 4.11 | ±0.048 | 0.236 | 5 | 0-0.075 | 0.74 | +0.050 | 1.2 | 11.3 | 0.9 | 7 | 1.15 | 1 | 0.6 | 28000 |
| 6 | 7 | 9 | 0.7 | ±0.02 | 5.26 | ±0.048 | 0.255 | 6 | 0-0.075 | 0.74 | +0.050 | 1.2 | 12.3 | 1.1 | 8 | 1.35 | 1.1 | 0.7 | 25000 |
| 7 | 8 | 11 | 0.9 | ±0.02 | 5.84 | ±0.048 | 0.474 | 7 | 0-0.09 | 0.94 | +0.050 | 1.5 | 14.3 | 1.25 | 9 | 1.8 | 1.3 | 1 | 22000 |
| 8 | 9 | 12 | 1 | ±0.03 | 6.52 | ±0.058 | 0.66 | 8 | 0-0.09 | 1.05 | +0.080 | 1.8 | 16.3 | 1.42 | 10 | 2.5 | 1.5 | 1.25 | 20000 |
| 9 | 10 | 14 | 1.1 | ±0.03 | 7.63 | ±0.058 | 1.09 | 9 | 0-0.09 | 1.15 | +0.080 | 2 | 18.8 | 1.6 | 11 | 3 | 1.6 | 1.5 | 17000 |
| 10 | 11 | 15 | 1.2 | ±0.03 | 8.32 | ±0.058 | 1.25 | 10 | 0-0.09 | 1.25 | +0.080 | 2 | 20.4 | 1.7 | 12 | 3.5 | 1.8 | 1.75 | 15000 |
| 12 | 13 | 18 | 1.3 | ±0.03 | 10.45 | ±0.07 | 1.63 | 12 | 0-0.11 | 1.35 | +0.080 | 2.5 | 23.4 | 3.1 | 15 | 4.7 | 1.9 | 2.3 | 13000 |
| 15 | 16 | 24 | 1.5 | ±0.03 | 12.61 | ±0.07 | 3.37 | 15 | 0-0.11 | 1.55 | +0.080 | 3 | 29.4 | 7 | 20 | 7.8 | 2.2 | 3.3 | 11000 |
| 19 | 20 | 31 | 1.75 | ±0.03 | 15.92 | ±0.07 | 6.42 | 19 | 0-0.11 | 1.8 | +0.080 | 3.5 | 37.6 | 10 | 25 | 11 | 2.5 | 3.6 | 7600 |
| 24 | 25 | 38 | 2 | ±0.03 | 21.88 | ±0.084 | 8.55 | 24 | 0-0.13 | 2.05 | +0.080 | 4 | 44.6 | 13 | 30 | 15 | 3 | 4 | 5500 |
| 30 | 32 | 42 | 2.5 | ±0.03 | 25.8 | ±0.084 | 13.5 | 30 | 0-0.13 | 2.55 | +0.080 | 4.5 | 52.6 | 16.5 | 36 | 23 | 3.5 | 5.3 | 4200 |
