| d1 | dk | c | |||
|---|---|---|---|---|---|
| nominal | max. | min. | max. | min. | |
| 1.4 | 1.4 | 1.35 | 2.7 | 2.3 | 0.42 |
| 1.6 | 1.6 | 1.55 | 3 | 2.6 | 0.48 |
| 2 | 2 | 1.95 | 3.7 | 3.3 | 0.6 |
| 2.5 | 2.5 | 2.425 | 4.6 | 4.2 | 0.75 |
| 3 | 3 | 2.925 | 5.25 | 4.95 | 0.9 |
| 4 | 4 | 3.9 | 7.25 | 6.75 | 1.2 |
| 5 | 5 | 4.9 | 9.1 | 8.5 | 1.5 |
| 6 | 6 | 5.9 | 10.8 | 10.2 | 1.8 |
| 8 | 8 | 7.85 | 14.4 | 13.6 | 2.4 |
| 10 | 10 | 9.85 | 16 | 14.9 | 3 |
| 12 | 12 | 11.8 | 19 | 17.7 | 3.6 |
| 16 | 16 | 15.8 | 26 | 23 | 4. |
| 20 | 20 | 19.8 | 31.5 | 30.7 | 6 |
